Your Site Plan Got Rejected? Here’s What Reviewers Actually Look For
Most delays aren’t about bad design. They’re about missing dimensions, easements you didn’t see, and setback measurements from the wrong point.
You submitted everything. The contractor is ready. Then the email arrives: “Corrections required.” Now you’re back in queue for 4‑6 weeks. Carrying costs stack up. The crew moves to another job. All because a note was missing or a line was drawn from the wrong spot. That’s what this page is for – to stop that from happening again.
Why Your Plan Was Rejected (Most Common Triggers)
Reviewers measure to the furthest projection – roof overhang, eaves, gutters, chimneys. If you measured from the foundation wall, you’re off by 1‑2 feet. That’s a redline. Fix: Always show setback from the roofline.
Cities want the recorded instrument number. Saying “utility easement” isn’t enough. Without the book/page, the reviewer can’t verify it exists. Fix: We pull easement documents from county records and add the reference.
Many cities require a note that says “property not located in FEMA Zone AE or VE.” No note = incomplete submission. Fix: Add the FEMA panel number and a statement.
If your lot is 5,000 sq ft and your house + driveway + patio exceed 2,500 sq ft (50%), you may be over the limit. Reviewers check. Fix: Calculate total impervious area and show it on the plan.
GIS rounds numbers (e.g., 40′ instead of 40.17′). Reviewers pull the plat. If they don’t match, they reject. Fix: Use the exact bearings and distances from the recorded plat.
They can’t orient your plan. Automatic rejection. Fix: Always include a north arrow with a clear direction.
If the reviewer can’t tell what’s new, they’ll mark “insufficient documentation.” Fix: Use different line types or hatching.
What Reviewers Don’t Tell You (But Will Reject You For)
They have internal checklists not published online. You won’t find “add flood note” in the public code. But it’s in their binder. We’ve collected these from dozens of cities.
They reject ambiguity to avoid liability. If your plan says “approx.” or leaves a dimension blank, they won’t call to ask. They’ll stamp “rejected.”
They compare your plan to the recorded plat – not to Google Earth. If your drawing shows a property line that doesn’t match the plat, you lose.
Engineering reviewers care about drainage even if the planning checklist doesn’t mention it. Water doesn’t respect property lines. They will ask for flow arrows and grading notes.
Fire department reviews access. If your driveway width is too narrow or the turning radius is too tight, they’ll flag it – even if the building code doesn’t spell it out.
City‑Specific Rejection Patterns (What Reviewers in Your City Actually Flag)
| City | What Gets Rejected Most | Why |
|---|---|---|
| Austin, TX | Missing watershed zone note (Barton Springs, Edwards Aquifer) | Code requires impervious cover limits by zone. No note = reject. |
| Dallas, TX | Tree protection survey missing | Any tree over 19″ caliper must be shown. Omit it = redline. |
| Houston (Harris County), TX | No flood panel reference | Even outside flood zone, they want the panel number. |
| Phoenix, AZ | Grading plan missing on slopes >2% | Their drainage review is aggressive. Flat drawings get rejected. |
| Denver, CO | ADU setback measured from main house incorrectly | Code says distance to primary structure, not property line. Many miss that. |
| Colorado Springs, CO | Hillside development note missing | Slopes over 15% trigger extra requirements. No note = incomplete. |
| Tampa, FL | Saltwater intrusion disclosure absent | Required for properties near coast. Easy to forget. |
| Charlotte, NC | Airport overlay zone note missing | Proximity to CLT triggers noise and height restrictions. Not shown = reject. |
Why Cities Request Revisions That Aren’t in the Code (And How to Handle It)
This is the most frustrating part of the permit process. You read the ordinance. You followed the checklist. Then the reviewer asks for something you’ve never seen before.
Why they do it:
Internal review sheets – The city has an unpublished checklist. It might say “verify utility easement recording.” You didn’t know.
Past project failures – A previous applicant built over a gas line. Now every plan gets a “utility location note.”
Interdepartmental handoffs – Planning approves. Engineering adds new comments. The code doesn’t mention engineering requirements in the planning section.
Safety overreach – The code says 10′ setback. The reviewer asks for 12′ because the property is next to a school. They can’t legally require it, but they’ll ask.
What to do:
Don’t argue unless it’s impossible. Adding a note is faster than appealing.
Ask for the code reference. Sometimes they’ll withdraw the request if they can’t cite it.
Call the reviewer. A 2‑minute phone call can clarify what they actually need. Emails get ignored.
Get it in writing. If they say “add a note,” add it. If they reject again, you have a record.
Our approach: We’ve seen hundreds of these unwritten requests. We maintain a database of city‑specific “ghost requirements.” When we prepare your plan, we include them before you submit.
How to Avoid a Second Round of Revisions
Add the flood note even if you’re not in a flood zone. Add the easement book/page even if you think it’s obvious. Reviewers never reject a plan for having too much information.
Pull the actual plat from the county recorder. Use its dimensions. GIS is for assessment, not legal approval.
Eaves, gutters, bay windows, chimneys – they all count. If you measure from the foundation wall, you will be wrong.
Not just “utility easement.” Add “Book 1234, Page 567.” That’s what they want.
Even a 2% slope needs flow arrows. Add a sentence: “Stormwater will be directed to street via swale.”
Use different line types. Label them. Don’t make the reviewer guess what’s new.
Sketches get rejected immediately. Scaled, layered PDFs get reviewed.
Real Case Stories
The plan: Perfect setbacks, clear dimensions, utility connections shown.
The rejection: “Watershed zone not identified. Resubmit with Barton Springs Zone note.”
The fix: Added “Property located in Barton Springs Zone – impervious cover limited to 15%.”
Outcome: Approved on second round. Lost 3 weeks.
The plan: Showed the garage, setbacks, easements.
The rejection: “Protected tree (19″ oak) within dripline of proposed structure. Tree survey required.”
The fix: Hired an arborist, added a tree preservation note.
Outcome: Approved after 6 weeks of delays.
The plan: Drawn by a civil engineer, looked complete.
The rejection: “Flood zone reference missing.” Property is in Zone X (low risk). Still rejected.
The fix: Added “FEMA Panel 48201C0375G, Zone X – no flood hazard.”
Outcome: Approved in 10 days.
FAQ – Questions Homeowners and Contractors Actually Ask
Yes, if the structure is permanent. A fence 2 feet over the property line is still a violation. Reviewers need to verify location.
Because the checklist is incomplete. Internal review sheets, engineering comments, and fire department requirements aren’t on the website.
You can try. It will be rejected. No scale, no north arrow, no dimensions.
To the nearest 0.01 foot (1/8 inch). If you round 40.17′ to 40′, they will reject.
Plot plan: simpler, for fences, sheds, small decks. Site plan: includes utilities, easements, grading, flood notes. Some cities use the terms interchangeably – check your checklist.
Multiple departments review separately. Planning approves, then engineering adds new comments. That’s not a mistake; it’s their workflow.
No. The utility can force removal at your cost. Your site plan must show the easement and keep structures clear.
Flat lots still need to show where water goes. If you don’t direct it, it might go to the neighbor. That’s a lawsuit waiting to happen.
4‑6 weeks in most cities. You go to the back of the queue. That’s why getting it right the first time matters.
You get another correction letter. Some cities allow unlimited cycles. Others require a new application after 2‑3 rejections – plus new fees.
Not usually. We use recorded plats and deed descriptions. If your property has a known boundary dispute, we’ll recommend a survey.
We revise for free until it’s approved. Send us the correction letter. We handle it.
Most revisions in 24 hours. Complex changes (moving a building, re‑drawing easements) take 48 hours.
Yes, using recorded plats. But if physical conditions have changed, there’s risk. We’ll note limitations.
